4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
1 / 5
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift

4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift

Customization: Available
After-sales Service: After-Sale Support
Warranty: 1 Year
Send Inquiry

Product Description

Basic Info.

Model NO.
AMWP4.8-6100
Application
Warehouse Crane
Lift Mechanism
Vertical Telescope
Carrying Capacity
Middle-Level
Moves
Self-propelled
Driven Type
AC
Running Mode
Moving
Feature
Explosion-Proof
Certification
CE, ISO 9001
Transport Package
Standard Seaworthy Package
Specification
1300x700x1100
HS Code
8501101000

Product Description

Specification:

ModelAMWP4.8-6100
Rated capacity227kg
Outreach working platform load114kg
Max. Working height6.8m
Max.Platform height4.8m
Overall length1.36m
Overall width0.76m
Overall height1.98m
Platform size1.3m*0.7m*1.1m
Platform outreach size0.51m
Max.ground clearance(stowed)0.1m
Max.ground clearance(raising)0.023m
Wheelbase1.04m
Min.turning radius(inner tyre)0.3m
Min.turning radius (outer tyre)1.8m
Lift motor/Drive motor1.3KW/0.5kw
Drive speed(stowed)4km/h
Drive speed (raising)1.1km/h
Lift/down speed41.5/42 sec
Battery2×12V/100Ah
Charge24v/15A
Max. Gradeability25%
Max.Working angle1.5°
TyreΦ305*100mm
Total weight980kg
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift
4.8m Self-Propelled Vertical Mast Aerial Working Boom Lift

Frequently Asked Questions

1. What is the maximum working height of the AMWP4.8-6100?
The maximum working height reaches up to 6.8 meters, with a maximum platform height of 4.8 meters.
2. What is the load capacity of this vertical mast lift?
It has a rated capacity of 227kg, while the outreach working platform can support up to 114kg.
3. Can this lift be used in narrow warehouse aisles?
Yes, with an overall width of only 0.76m and an inner turning radius of 0.3m, it is designed specifically for tight warehouse spaces.
4. What type of power system does it use?
The unit is self-propelled using an AC drive system, powered by two 12V/100Ah batteries with a 24V/15A charger.
5. What safety features and certifications are included?
This model is explosion-proof and holds both CE and ISO 9001 certifications, ensuring high safety and quality standards.
6. How fast can the AMWP4.8-6100 move?
When stowed, it can travel at a speed of 4km/h. For safety, the speed is reduced to 1.1km/h when the platform is raised.
