🔵 Basic Information
Application
Workshop, Shipboard, Warehouse, Building Crane
Lift Mechanism
Articulated Lift
Carrying Capacity
Special Weight Level
Certification
GS, CE, ISO 9001
💡 Product Advantages & Characteristics
✔Leading international level system technology.
✔Fully humanized design based on human engineering principles.
✔High-reliability components including imported seals, bearings, and electrical parts.
✔Environmentally friendly power systems meeting emission standards.
✔Stable electronic control assembly and high-quality imports for electrical components.
✔Strict adherence to ISO9000 and CE standards for production quality.
✔Comprehensive after-sales support and timely spare parts supply.
📊 Product Parameters
|
| Max. Working Height | 13.5m |
| Max. Platform Height | 11.5m |
| Max. Operating Radius | 5.63m |
| Max. Spanning Height | 5.4m |
| Platform Dimensions | 1.26m x 0.712m |
| Overall Length | 4.04m |
| Overall Height (Stowed) | 2.05m |
| Overall Width (Stowed) | 1.50m |
| Ground Clearance | 0.12m |
|
| Max. Lift Capacity | 215kg |
| Platform Occupants | 2 |
| Turntable Rotation | 365° Non-continuous |
| Gradeability | 36% |
| Weight | 3760kg |
|
| Power Source | Battery 8×6V (220Ah) |
| Charger | 48V/30A |
| Hydraulic Tank | 23L |
❓ Frequently Asked Questions
What is the maximum working height of this articulated boom lift?
The GTZZ12E model offers a maximum working height of 13.5 meters and a platform height of 11.5 meters.
How many people can work on the platform simultaneously?
The platform is designed to safely accommodate up to 2 occupants with a maximum lift capacity of 215kg.
Is this lift suitable for sloped surfaces?
Yes, it features a gradeability of 36% and includes a tilt warning system for lateral (2°) and front/rear (3°) inclines.
What kind of power source does the GTZZ12E use?
It is powered by a high-capacity battery system (8×6V, 220Ah) and comes with a 48V/30A charger.
What are the safety certifications for this equipment?
The product is fully certified with GS, CE, and ISO 9001 standards to ensure international safety compliance.
Does the platform offer rotation capabilities?
Yes, the platform can rotate ±90°, and the turntable offers a 365° non-continuous rotation for precise positioning.
